Beschreibung
features:
●Day and night | ●Blacklight |
●1500TVL | ●Super WDR |
●4.5V-27V | ●FOV125° |
Bullet Points:
Featuring a blacklight technology, Ratel Pro displays real color images during the day and displays to black-and-white visuals at night, ensuring optimal visual performance in diverse lighting conditions.
![](https://cdn.shopify.com/s/files/1/0036/3921/4169/files/7_9d98a03b-9411-417a-923b-3db256ccd3d0.jpg?v=1704447001)
Ratel Pro delivers excellent daytime clarity, setting new standards in visual excellence within the analog camera domain.
![](https://cdn.shopify.com/s/files/1/0036/3921/4169/files/4_c8cba48a-8f61-47c9-b18c-1263b983b700.jpg?v=1704446211)
Using BSI 1/1.8INCH large sensor and enhanced algorithm, the illumination is doubled compared to ordinary night vision cameras. Even in low-light conditions, Ratel Pro achieves outstanding night vision, providing clear and reliable imagery for uncompromised visibility.
![](https://cdn.shopify.com/s/files/1/0036/3921/4169/files/8_380f6439-a97e-49af-b090-33d771db31b6.jpg?v=1704704753)
Supports WDR, bounteously satisfying the pursuit of detailed shooting whether in bright or dark environments.
![](https://cdn.shopify.com/s/files/1/0036/3921/4169/files/3_df1ffbf2-b088-4e3e-af6d-83fb62385d9b.jpg?v=1704703836)
![](https://cdn.shopify.com/s/files/1/0036/3921/4169/files/2_53806ce6-542e-41c2-bed7-a0feb6b96c68.jpg?v=1704446340)
Designed with 125° FOV, Ratel Pro offers pilots a natural visual experience during flight, restoring the authenticity of the scenes.
![](https://cdn.shopify.com/s/files/1/0036/3921/4169/files/5_2955ab9e-f2aa-4456-ab73-9ff81a93a230.jpg?v=1704446372)
Featuring a metal case, the lightweight design improves durability and heat dissipation.
![](https://cdn.shopify.com/s/files/1/0036/3921/4169/files/6_fd998f88-5cd2-41a1-8f72-70b81b5347fd.jpg?v=1704693378)
Model | Ratel PRO |
Image Sensor | 1/1.8″ Inch sensor |
Horizontal Resolution | 1500TVL |
TV System | NTSC & PAL (changeable) |
IMAGE | 16:9 & 4:3 (changeable) |
WDR | Super WDR (HDR) |
Min. Illumination | 0.00001 lux |
Lens | 5Mega |
Color | Black |
Synchronization | Internal |
Electronic Shutter | PAL: 1/50~100,000; NTSC: 1/60~100,000 |
S/N Ratio | >60dB (AGC OFF) |
Video Output | CVBS |
OSD manual | Support |
DNR | 3-DNR |
FOV | 125° |
Language | (ENGLISH/中文/繁中文/Русский/ESPANOL/ITALIANO/ FRANCAIS/POLSKIM/ PORTUGUES/日本语) |
Day/Night | Auto/Color/B&W/EXT |
Dimensions | 19mm*19mm |
Wide Power Input | DC 4.5-27V |
Work Temperature | -20℃~+60℃ |
Work Humidity | 20%~80% |
Weight | 9.5g |
