BetaFPV TWIG Mutant 4” (Crossfire)

CHF 234.90

NICHT am Lager

Kategorie:

Beschreibung

Specification

  • Item: TWIG Mutant 4”
  • Weight: 148.3g (Excluded battery)
  • FC&ESC: Toothpick F4 2-4S AIO FC 20A(BLHeli_S) V3
  • Motors: 1506 3000KV Brushless Motor
  • Props: Gemfan 4032 3-Blade Props
  • Camera: Caddx Ratel Camera
  • VTX: A01 25-200mW 5.8G VTX
  • Frame: TWIG Mutant Frame
  • Canopy: Canopy for Mini Cam V3 Black
  • Receiver Option: Frsky FCC/ Frsky LBT /TBS Crossfire
  • Battery: 4S battery, like 450mAh 4S battery/850mAh 4S battery (Excluded)
  • Flight time: With the 850mah 4S Battery, we can get 7:30mins on smoothly flight, and 4:00mins for insane flight

Motor

RCINPower 1506 3000KV Motor-Rated at 3000kv, this 1506 motor hits the nice spot for the high-powered 4S 4” toothpick builds and is with the ability to swing up to 4″ props with ease.

Please note, the appearance of 1506 motor is changed, but it is made from the same factory as the previous version.

Flight Controller

Toothpick F4 2-4S AIO FC 20A(BLHeli_S) V3 – This board can handle 20A continuous current(25A burst) well. Add 8M Flash chip for Betaflight Black Box. With 3 full UARTs (UART1, UART2 and UART6), pilots could use one UART for DJI digital FPV unit or Caddx Vista digital FPV unit and the other UART for external receiver like TBS Crossfire.

Camera & VTX

The Caddx Ratel is a great camera choice for both night flight as well as during the day! Equipped with a high quality 1/1.18″ HDR sensor, it provides up to 0.0001 Sensitivity of lux. It is very versatile in that you can switch between PAL and NTSC video and also between 4:3 and 16:9 video formats. Latency is super low at only 8ms.

A01 VTXboard is lighter and perfectly suitable for canopy with switchable output power between 25mW and 200mW. SmartAudio is available for VTX remote control in default.

Dieses Produkt darf in der Schweiz nicht betrieben werden. Nicht für schweizer Kunden.
